The AEV-48 power supply is a cost-effective solution when replacing older power supplies that use modern actuator technology. As a result, the effort for the complete replacement of power supply and control technology remains low.
The AEV-48 power supply is housed in a separate housing measuring 500 x 500 x 200 mm. The power supply is designed so that it can easily be connected to the old SHE systems. The AEV-49 is connected to the control modules, for which only a few connection lines are necessary. Especially for RZ and ESM controllers, the AEV-48 is a cost-effective solution.
The power supply also includes the power supply with charging card and rechargeable batteries according to DIN EN 12101-10. All outgoing terminals are prepared for transfer to the on-site installed control.
| Matchcode | alternative energy supply AEV-48 |
| Article name | alternative energy supply AEV-48 |
| Part number | ST4 3327 |
| Output current | 48 |
| Housing length | 500 |
| Housing width | 500 |
| Housing height | 200 |
The AEV-48 is an alternative power supply with a housing dimension of 500 x 500 x 200 mm. It is used when old power supplies need to be replaced for modern actuator technology to work.
